| Assembly / Parameter Name | Model / Specification | Assembly / Parameter Name | Model / Specification |
|---|---|---|---|
| Vehicle Name | EV 4×2 Garbage Truck | Model | STQ5125ZXLNBEV |
| Curb Weight | 5,250 kg | Cargo Dimension (mm) | 3800 × 2100 × 1000 |
| Driving Type | 4×2 | Wheelbase (mm) | 3300 |
| Battery Brand | CATL | Battery Capacity | 131 kWh |
| Front Axle | 2.5 T | Rear Axle | 6 T |
| Speed Ratio | 6.33 | Tire | 245/70R17.5LT 18PR |
| Motor Power (Rated/Peak) kW | 110 / 210 | Driving Range (km) | 200 |
| Standard Config | Air conditioning, ABS, fast charging | ||
| GVW (kg) | 11,995 | ||
| Max. Loading Capacity (kg) | 20,000 |
- Improved Performance: Compared to the previous light-duty EV garbage truck, this model has a larger 131 kWh battery and a more powerful 210 kW peak motor, boosting the range up to 200 km. This makes it suitable for longer municipal routes or suburban waste collection.
- Larger Cargo Box: The cargo box measures 3800 × 2100 × 1000 mm, providing a significantly larger volume for waste collection.
- Heavy-Duty Drivetrain: It features a stronger rear axle (6T) with a steep 6.33 ratio, optimized for the frequent stop-and-go nature of garbage collection with a full load.
- Anomaly Note: The "20,000 kg max loading capacity" is physically impossible for a truck with an 11,995 kg GVW. The actual legal payload is 6,745 kg (approx. 6.7 tons). For marketing, emphasize the large cargo box volume, the 200 km range, and zero emissions rather than the 20-ton payload.
